D-TECT 200 C
Detectors · Part No. 06010816K0
- Category
- Detectors
- Part number
- 06010816K0
- Power
- Corded (mains)
- HSN
- 90221900
- GST rate
- 18%
About this tool
The D-tect 200 Professional detects all common objects and illustrates them clearly while making documentation easy. Equipped with Bosch Radar Technology and an improved HMI, it stands for safer and more precise detection. Multiple view options allow the ideal application for different situations, such as Spot View, that makes detection in hard-to-reach locations easier. The detector enables instant documentation which allows data to be transferred via USB-C or MicroSD-Card connection.
Equipment & Application
The D-tect 200 Professional supports all round detection, enabling safer construction work during drilling.
Additional Information
The D-tect 200 Professional detects objects in depths of up to 200 mm and indicates the object´s depth.
Technical data
20 published figures- Dust and splash protection
- IP5X
- Max. detection depth
- 200 mm
- Bosch Radar Technology
- Yes
- Detectable objects
- live cables, non-live cables, magnetic metals (e.g. iron), non-magnetic metals (e.g. copper), low-voltage & data cables (Three-phase power cables, cavities), Empty plastic pipes, water-filled plastic pipes, wooden substructures
- Data transfer
- Micro-SD Card, USB-C®
- Detection depth, dry concrete, max.
- 200 mm
- Detection depth, early age concrete, max.
- 60 mm
- Detection depth, other wall types, max.
- 80 mm
- Detection depth, magnetic metal, max.
- 200 mm
- Detection depth, non-magnetic metal, max.
- 80 mm
- Detection depth, live cables, max.
- 80 mm
- Detection depth, wooden substructures, max.
- 38 mm
- Accuracy
- ± 5.0 mm
- Views
- Object view, Signal View, Signal View 2D, Spot view
- Wall types
- Panel Heating, Early age concrete, Concrete, Horizontal coring brick, Vertical coring brick, Brick/Universal, Drywall
- Updatable
- Yes
- Material identification
- Non-magnetic metal, Non-metal material, Live object, Magnetic metal
- Power supply
- 4 x 1.5 V LR6 (AA), 10.8 V Li-Ion battery, 12 V Li-Ion battery
- Weight, approx.
- 0.64 kg
- Additional function
- Leakage detection, Distance measurement
Description and figures published by Bosch at bosch-professional.com. We reproduce them as published and do not add to them.
