Bare tool — no battery or charger included
This tool is sold Solo. It comes with no battery and no charger, and will not switch on until you add both. Add a compatible 12V battery and charger below to get a working tool.
GTC 600 C ( Bare Tool ) - Thermal
Thermal Measurement · Part No. 06010835K1
- Category
- Thermal Measurement
- Part number
- 06010835K1
- Power
- Cordless · 12V battery
- HSN
- 90275090
- GST rate
- 18%
- Battery platform
- 12V
About this tool
Detect temperature differences quickly and easily, even outdoors – Bosch´s thermal camera GTC 600 C Professional offers detailed visualisations of temperature differences and allows for smart documentation. It features a high thermal resolution and wide measuring range for a maximum of thermal measuring applications. Convenient voice note, the Bosch ThermalOn app and the GTC Transfer Software enable easy documentation of thermal images. An intuitive user interface and seamlessly integrated features such as emissivity value presets and an improved gallery with both IR and visual images deliver successful results in minimum clicks.
Equipment & Application
This tool is ideal for detecting insulation problems and unwanted hot or cold spots.
Additional Information
The robust GTC 600 C can withstand falling from a height of 2 m, has a protection class of IP54, and can be used on jobsites even under the toughest conditions. Additionally, its 12V Li-ion batteries give the tool an outstanding runtime. Documenting and sharing measured values is easy with the corresponding Bosch app thanks to its Simple Exchange functionality for transferring data. This thermal camera has a high accuracy of ±2.0°C* and a wide temperature range of -20°C to +600°C.
Technical data
24 published figures- Battery voltage
- 12.0 V
- Measurement range
- -20 °C to +600 °C
- Measuring accuracy of IR
- ± 2.0 °C
- Measuring application
- Thermal image
- Data transfer
- Wi-Fi, USB-C®
- Thermal sensitivity (NETD)
- <=50 mK
- Thermal image refresh rate
- 9 Hz
- Frame buffer (number of images each with audio)
- 350
- File format of audio
- .wav
- Resolution
- 0.1 °C
- Size of IR sensor
- 256 Pixel x 192 Pixel
- Number of measuring points
- 49,152
- Frame buffer (number of images)
- 600
- File format of image
- .jpg
- Shock protection
- 2 m
- Dust and splash protection
- IP54
- Weight
- 0.6 kg
- Size of display
- 3.5"
- Operating temperature
- -10 – 45 °C
- Storage temperature
- -20 – 50 °C
- Focus distance, minimum
- 0.3 m
- Tool dimensions (L x W x H)
- 109 x 101 x 213
- Net weight
- 1.073 kg
- Gross weight
- 1.073 kg
Description and figures published by Bosch at bosch-professional.com. We reproduce them as published and do not add to them.
